Security Film
First, what is safety film…?
Safety film is the film that goes through the same production process as other normal film, but it has extra layers of polyester and extra adhesive layers that tightly glue them together. The strength and the quality of the film is depending and based on how many multiple layers of polyester and adhesive is added. The installation of safety film can enhance the strength of a regular glass and provide an additional buffer/protection against external impacts in an event of accidents, earthquakes, bomb blasts/explosions, and storms, etc.
Safety film will encapsulate the damaged glass by holding them together to protect people, property and possessions from the danger of flying shattered glass. However, it also depends on how thick the frame and the window are. Normally, the thickness of a regular high-quality window film should be between 1.5-2.0 mil. (.0015 - .0020 inches), but a safety film with the thickness of 2.0 mil. is only a grade C film. A high-quality safety film must have the thickness of at least 4 mil. or more than 100 microns.
*Safety film cannot prevent the glass breakage.
What will you and your family benefit by installing Lamina LLumar safety film
- Protect lives and property from intruder and accidental damage.
- Protect lives and property from natural disasters like earthquakes and storms.
- Protect lives and property from bomb blast/explosions.
- Provide solar energy rejection for up to 79% (depending on each film model).
- Provide up to 99% of protection against UV rays.
- Provide a range of product options, including film types and colors.
- Provide a range of product options, including film types and colors.
- Reduce the work for your car and building A/C, prolong the life of the car and A/C engine, as well as help you save on the fuel and electric bill.
- Increase the glamouring appearance of your car and building.
- Decreases fading of interior draping and fabrics in your car
- High resistance to abrasion with transparent anti-scratch coating for easy clean and care
- Reasonable price for a world-standard quality product
- You can install Lamina LLumar safety film at more than 270 authorized retailers national-wide.
Lamina LLumar – a trusted window and safety film for many buildings globally.
Lamina LLumar is a well-known window and safety film that gained high trust from many countries in Europe and America due to its supreme quality, high manufacturing standard and excellent level of performance to guard the people, property and possessions. For these reasons, The U.S. Department of State, The U.S. Army Corps of Engineers, The U.S. Embassies around the world and many more important places and office buildings have all chosen to install Lamina LLumar.
In Thailand, Lamina LLumar window and safety film are widely accepted by both public and private sectors. Many places and building such as Electricity Generating Authority of Thailand (EGAT), Electricity Generating Public Company Limited (EGCO), Mahidol University, Dhurakit Pundit University, Vajiravudh College, Siam Commercial Bank Public Company Limited, Black & Decker (Thailand) Company Limited, Block Buster, KFC, Rama III Tower, River King Cruise have all chosen to install Lamina LLumar safety film. In addition, countless number of car owners have also trusted and chosen the Lamina LLumar.
Safety Film for Building: Models and Features
(Physical features and properties)
Model |
Color |
Film Thickness |
Single or Multiply |
Tensile Strength |
Break Strength |
Elongation at Break |
Peel Strength |
Puncture |
XSCLSRPS15 |
Transparent |
.015"
(375 micron) |
Multiply |
23,345 |
373 |
149% |
>1,550 g/inch
(>3.4 lb/inch) |
226 |
XSCLSRPS11 |
Transparent |
.011"
(275 micron) |
Multiply |
27,318 |
301 |
159% |
>1,550 g/inch
(>3.4 lb/inch) |
184 |
XSR20SISRPS8 |
Silver |
.008"
(200 micron) |
Multiply |
29,505 |
235 |
140% |
>2,850 g/inch
(>6.3 lb/inch) |
146 |
XSP50NSRPS8 |
Smoke |
.008"
(200 micron) |
Multiply |
29,505 |
235 |
140% |
>2,850 g/inch
(>6.3 lb/inch) |
146 |
XSCLSRPS7 |
Transparent |
.007"
(175 micron) |
Single |
27,614 |
193 |
211% |
>3,200 g/inch
(>7 lb/inch) |
121 |
XSR20SISRPS4 |
Silver |
.004"
(100 micron) |
Multiply |
25,714 |
101 |
137% |
>3,200 g/inch
(>7 lb/inch) |
77 |
XSP50NSRPS4 |
Smoke |
.004"
(100 micron) |
Multiply |
25,714 |
101 |
137% |
>3,200 g/inch
(>7 lb/inch) |
77 |
XSCLSRPS4 |
Transparent |
.004"
(100 micron) |
Single |
33,100 |
132 |
167% |
>3,200 g/inch
(>7 lb/inch) |
74 |
XSCLSRPS15 |
Color |
Transparent |
Film Thickness |
.015" (375 micron) |
Single or Multiply |
Multiply |
Tensile Strength |
23,345 |
Break Strength |
373 |
Elongation at Break |
149% |
Peel Strength |
>1,550 g/inch (>3.4 lb/inch) |
Puncture |
226 |
XSCLSRPS11 |
Color |
Transparent |
Film Thickness |
.011" (275 micron) |
Single or Multiply |
Multiply |
Tensile Strength |
27,318 |
Break Strength |
301 |
Elongation at Break |
159% |
Peel Strength |
>1,550 g/inch (>3.4 lb/inch) |
Puncture |
184 |
XSR20SISRPS8 |
Color |
Silver |
Film Thickness |
.008" (200 micron) |
Single or Multiply |
Multiply |
Tensile Strength |
29,505 |
Break Strength |
235 |
Elongation at Break |
140% |
Peel Strength |
>2,850 g/inch (>6.3 lb/inch) |
Puncture |
146 |
XSP50NSRPS8 |
Color |
Smoke |
Film Thickness |
.008" (200 micron) |
Single or Multiply |
Multiply |
Tensile Strength |
29,505 |
Break Strength |
235 |
Elongation at Break |
140% |
Peel Strength |
>2,850 g/inch (>6.3 lb/inch) |
Puncture |
146 |
XSCLSRPS7 |
Color |
Transparent |
Film Thickness |
.007" (175 micron) |
Single or Multiply |
Single |
Tensile Strength |
27,614 |
Break Strength |
193 |
Elongation at Break |
211% |
Peel Strength |
>3,200 g/inch (>7 lb/inch) |
Puncture |
121 |
XSR20SISRPS4 |
Color |
Silver |
Film Thickness |
.004" (100 micron) |
Single or Multiply |
Multiply |
Tensile Strength |
25,714 |
Break Strength |
101 |
Elongation at Break |
137% |
Peel Strength |
>3,200 g/inch (>7 lb/inch) |
Puncture |
77 |
XSP50NSRPS4 |
Color |
Smoke |
Film Thickness |
.004" (100 micron) |
Single or Multiply |
Multiply |
Tensile Strength |
25,714 |
Break Strength |
101 |
Elongation at Break |
137% |
Peel Strength |
>3,200 g/inch (>7 lb/inch) |
Puncture |
77 |
XSCLSRPS4 |
Color |
Transparent |
Film Thickness |
.004"
(100 micron) |
Single or Multiply |
Single |
Tensile Strength |
33,100 |
Break Strength |
132 |
Elongation at Break |
167% |
Peel Strength |
>3,200 g/inch (>7 lb/inch) |
Puncture |
74 |
(Optical properties)
Model |
Color |
% Solar Energy Rejection |
% Visible Light Transmission |
% UV Protection |
Film Shading Coefficient |
% Visible Light Reflection |
% Solar Energy Transmission |
XSR20SISRPS4 |
Silver |
79 |
15 |
99 |
0.24 |
60 |
12 |
XSR20SISRPS8 |
Silver |
79 |
15 |
99 |
0.24 |
60 |
12 |
XSP50NSRPS4 |
Smoke |
44 |
48 |
99 |
0.64 |
13 |
48 |
XSCLSRS4 |
Transparent |
12 |
89 |
95 |
0.99 |
9 |
84 |
XSP50NSRPS8 |
Smoke |
44 |
48 |
99 |
0.64 |
13 |
48 |
XSCLSRPS7 |
Transparent |
12 |
89 |
95 |
0.99 |
9 |
88 |
XSCLSRPS11 |
Transparent |
12 |
87 |
95 |
0.99 |
10 |
82 |
XSCLSRPS15 |
Transparent |
14 |
87 |
95 |
0.99 |
10 |
82 |
XSR20SISRPS4 |
Color |
Silver |
% Solar Energy Rejection |
79 |
% Visible Light Transmission |
15 |
% UV Protection |
99 |
Film Shading Coefficient |
0.24 |
% Visible Light Reflection |
60 |
% Solar Energy Transmission |
12 |
XSR20SISRPS8 |
Color |
Silver |
% Solar Energy Rejection |
79 |
% Visible Light Transmission |
15 |
% UV Protection |
99 |
Film Shading Coefficient |
0.24 |
% Visible Light Reflection |
60 |
% Solar Energy Transmission |
12 |
XSP50NSRPS4 |
Color |
Smoke |
% Solar Energy Rejection |
44 |
% Visible Light Transmission |
48 |
% UV Protection |
99 |
Film Shading Coefficient |
0.64 |
% Visible Light Reflection |
13 |
% Solar Energy Transmission |
48 |
XSCLSRS4 |
Color |
Transparent |
% Solar Energy Rejection |
12 |
% Visible Light Transmission |
89 |
% UV Protection |
95 |
Film Shading Coefficient |
0.99 |
% Visible Light Reflection |
9 |
% Solar Energy Transmission |
84 |
XSP50NSRPS8 |
Color |
Smoke |
% Solar Energy Rejection |
44 |
% Visible Light Transmission |
48 |
% UV Protection |
99 |
Film Shading Coefficient |
0.64 |
% Visible Light Reflection |
13 |
% Solar Energy Transmission |
48 |
XSCLSRPS7 |
ColorClear film |
Transparent |
% Solar Energy Rejection |
12 |
% Visible Light Transmission |
89 |
% UV Protection |
95 |
Film Shading Coefficient |
0.99 |
% Visible Light Reflection |
9 |
% Solar Energy Transmission |
88 |
XSCLSRPS11 |
Color |
Transparent |
% Solar Energy Rejection |
12 |
% Visible Light Transmission |
87 |
% UV Protection |
95 |
Film Shading Coefficient |
0.99 |
% Visible Light Reflection |
10 |
% Solar Energy Transmission |
82 |
XSCLSRPS15 |
Color |
Transparent |
% Solar Energy Rejection |
14 |
% transmittance |
87 |
% UV Protection |
95 |
Film Shading Coefficient |
0.99 |
% Visible Light Reflection |
10 |
% Solar Energy Transmission |
82 |
